Обзор продукта
The I-1 is an agile three-wheeled industrial road sweeper without cab, engineered for highly manoeuvrable, efficient cleaning across both indoor and outdoor commercial facilities. Featuring a 140 cm cleaning path, a 220 L high-capacity hopper, a 60 L water tank for dust suppression, and a robust 1200W DC drive motor, the I-1 delivers an outstanding cleaning efficiency of up to 6,000 m²/h. Its reinforced powder-coated steel chassis and industrial solid tires ensure long-lasting durability in demanding working environments.
Технические характеристики
| Нет. | Параметр | Ценить |
|---|---|---|
| 1 | Модель | I-1 |
| 2 | Type | Three-wheeled Sweeper without Cab |
| 3 | Overall Dimensions | 180 × 140 × 135 cm (L×W×H) |
| 4 | Gross Weight | 520 kg |
| 5 | Ширина очистки | 140 cm |
| 6 | Эффективность уборки | 6,000 m²/h |
| 7 | Вместимость бункера | 220 L |
| 8 | Емкость резервуара для воды | 60 L |
| 9 | Батарея | 48V / 70A (4 Pcs) |
| 10 | Working Hours | 3 – 4 h |
| 11 | Driving Power | 1200W DC Motor |
| 12 | Body Material | Reinforced Steel Sheet with Powder Coating |
| 13 | Tires | 350-8 Industrial Solid Tire × 3 |
| 14 | Gradeability (Max) | 25% |
| 15 | Max Travel Speed | 10 km/h |
Ключевые выдающиеся особенности
- Compact Three-Wheeled Agility: Zero-turn tight manoeuvrability enables effortless navigation around narrow warehouse aisles, pillars, and congested parking lanes.
- High Efficiency Sweeping (6,000 m²/h): Combines high sweeping speed with wide brush coverage to clean large areas quickly with minimal operator effort.
- Large 220L Waste Hopper: High-capacity debris storage drastically reduces the frequency of dumping stops, maximising productive cleaning time.
- Integrated Dust Suppression System: Equipped with a 60L water tank and mist spray nozzles to eliminate secondary dust emissions during operation.
- Heavy-Duty Powder-Coated Steel Body: Constructed with reinforced steel sheet to withstand harsh industrial impacts and resist long-term corrosion.
- Industrial Solid Tires & 25% Gradeability: Puncture-proof 350-8 solid tires and powerful 1200W motor easily conquer industrial ramps and uneven terrain.
Сценарии применения
- Logistics centres, transit warehouses, and loading docks
- Factory workshops, manufacturing plants, and assembly bays
- Commercial plazas, pedestrian paths, and open-air parking lots
- Property communities, residential compounds, and municipal parks
- Underground parking garages and storage compounds
