Product Overview
The I-41 is an elite, fully-enclosed four-wheeled industrial road sweeper built for the most demanding heavy-duty municipal and enterprise cleaning tasks. Featuring an ultra-wide 220 cm cleaning width and an astonishing coverage of up to 20,000 m²/h, it effortlessly masters massive areas. The fully-enclosed automotive-grade cabin provides full weather protection and comfort for all-season operation. Powered by a high-output 3000W DC motor and a massive 48V/150A 8-battery array, the I-41 delivers 6 to 8 hours of continuous, uncompromising sweeping performance.
Technical Specification
| No. | Parameter | Value |
|---|---|---|
| 1 | Model | I-41 |
| 2 | Type | Fully-enclosed Four-wheeled Sweeper |
| 3 | Overall Dimensions | 320 × 220 × 270 cm (L×W×H) |
| 4 | Gross Weight | 1,500 kg |
| 5 | Cleaning Width | 220 cm |
| 6 | Cleaning Efficiency | 20,000 m²/h |
| 7 | Hopper Capacity | 260 L |
| 8 | Water Tank Capacity | 300 L |
| 9 | Battery | 48V / 150A (8 Pcs) |
| 10 | Working Hours | 6 – 8 h |
| 11 | Driving Power | 3000W DC Motor |
| 12 | Body Material | Reinforced Steel Sheet with Powder Coating |
| 13 | Tires | 400-10 Industrial Solid Tire × 4 |
| 14 | Gradeability (Max) | 30% |
| 15 | Max Travel Speed | 12 km/h |
Key Outstanding Features
- Colossal 20,000 m²/h Efficiency: With an expansive 220 cm cleaning width, this flagship sweeper covers hectares of ground with single-operator ease.
- Fully-Enclosed All-Weather Cabin: Comfortable sealed driver cabin with panoramic glass windows ensures year-round operation in rain, dust, or cold.
- Ultra-Long 6–8 Hour Endurance: Equipped with an 8-piece 48V/150A battery configuration to handle intensive, full-day double shifts on a single charge.
- Massive 300L Water & 260L Hopper: Huge liquid and waste capacities allow extended run times without frequent water refill or debris discharge stops.
- Four-Wheel Automotive-Grade Stability: Four heavy-duty 400-10 solid tires and 3000W traction motor conquer 30% slopes and demanding outdoor terrain.
- Heavy Industrial Armored Frame: Built on a reinforced steel chassis designed to endure continuous heavy municipal and industrial duty cycles.
Application Scenarios
- City municipal roads, avenues, public squares, and urban expressways
- Heavy industrial complexes, steel mills, mining yards, and cement plants
- Airports, flight aprons, hangars, and major railway hubs
- Large logistics distribution parks, dry ports, and container terminals
- Exhibition grounds, theme parks, and large scenic municipal resorts
